Features

• Super Cleaning System™: Rinse the dishes. Clean the interior, including the filter. Choose the best program. This is our best invention.
• 8 Steel™ - More Steel Less Plastic: The main components of ASKO’s dishwashers are manufactured using high-quality steel instead of plastic. We think that quality is paramount.
• Aqua Safe™ System: An advanced safety system which ensures a leak-safe dishwasher day and night.
• Flexiracks™: ASKO Flexiracks™ from sturdy, nylon coated steel and are easily adjustable in different heights depending on which type of load you have.
• XXL Dishwashers: Our XXL dishwashers have a loading height of 23". Combined with the smart four level rack system the load is 40% more, with countless possibilities to make it all fit in.
• Self Cleaning: ASKO’s dishwashers have a Self-cleaning program to ensure that all vital parts are thoroughly cleaned. Use a recommended cleaning agent and the program on a regular basis for best result.
• Top Cutlery Tray: The top tray for cutlery and kitchen utensils is easy to remove for easy unloading. With a width of 12-3/4" the centered tray leaves plenty of room for tall wine glasses in the upper rack on each side of the tray. And with the Instant Lift™ you have the freedom to adjust the upper rack to be 1-1/2" or 2-1/4".
• Time Program: When you need clean plates in a hurry, just tell the machine how dirty the dishes are and how much time you have. The program then adjusts washing and rinsing to match your needs.
• Brushless Motor: A brushless motor is not only quieter and more reliable. It also consumes less energy.
• Speed Mode: When you need to get things cleaned in a hurry, the Speed mode is useful. It saves up to 50% of the normal time, by using more water and increased heating.
• Night Mode: Night mode reduces the noise with 2 dB thanks to lower pressure in the spray arm. Perfect at night or in a house with an open plan living area.
• Rinse & Hold: The Rinse and hold program allows for you to avoid dried leftovers while you wait for the dishwasher to get fully loaded. Saves time and energy over time.
• Aqua Level™ Sensor: The Aqua Level™ Sensor ensures an optimized water level, even if a bowl turns over and is filled with water. It also keeps the machine from starting if the water is turned off.
• Aqua Detect™ Sensor: The Aqua Detect™ Sensor monitors the inlet valves and the water level while the machine operates. For safety reasons, the drain pump’s capacity is five times the inlet valve’s.
• Power Zone Cutlery™: Power Zone Cutlery™ is a special nozzle spray zone for the cutlery basket that will make your cutlery dazzling clean. And, there is a similar nozzle for the knife basket.
• Kid Safe™: To stop small fingers from starting the dishwasher the Kid Safe™ makes the control panel easy to lock. This also prevents altering any settings by mistake.
• Instant Lift™: For our fully integrated dishwashers, the Anti-siphon solution safely keeps the water inside the machine. This is especially important if the dishwasher is placed above floor level.
• InstantLift™: Our InstantLift™ height adjustment system, allows for freeing up between 1-1/2" or 2-1/4" in the upper rack. A simple and flexible way to make room for it all.
• 7 Spray™: ASKO’s spray system consists of up to 7 effective spray zones to ensure a totally clean load. In the lower rack there are two power zones to take care of the dirtiest parts.
• 3 Level Basket: ASKO’s three level rack system allows you to optimize the load. Remove, adjust, fold and move the racks, tines and cutlery basket to meet your every need.

• Telescopic Rails: ASKO uses telescopic guide rails with ball bearings to make the racks glide smoothly and quietly. For easy loading and unloading, you can also take out the whole rack.
• 3 Spray Arms: The 3 spray-arm technique reaches every corner and with up to 10 highly effective spray zones, no dirt can escape. Not even your lasagna baking dish.
• Condensation Dry: ASKO dishwashers are some of the most advanced in the world. They’re packed with innovative features that make light work of all types of loads. Like our pre-rinse that saves you having to clean dishes before loading. Also, our Turbo Drying system that rapidly extracts condensation after the final wash so your dishes dry much faster.
• Outdoor Model: The durable outdoor version is made of stainless steel in all vital parts to protect it from the elements. Perfect for small summer houses or when you want to upgrade your outdoor kitchen.
• Touch Proof™: The ultra-thin, transparent TouchProof™ coating protects your dishwasher stains and grease. Easy to clean, scratch resistant it will keep your dishwasher looking brand new year after year.
• 16 Loading Capacity: The world’s biggest load capacity. The latest addition to our rack system is a flexible top cutlery tray with its own spray arm and space for sixteen sets of cutlery, small bowls, or other utensils that can be difficult to load. The width of the top cutlery tray has been optimized to make room for tall glasses in the upper rack and, if more space is needed simply take the top cutlery tray out.
• 15 3/4" Plates in Lower Rack: Our XXL dishwashers have room for a 40 cm big plate in the lower rack when the middle rack is removed and the upper rack in the upmost position.
• Pop Out Door: When a program is completed, the Door Pop-Out function opens the dishwasher door automatically to remove the steam inside.
• Knife Holders: Knives are sensitive things, so too are fingers. That is why we have done everything possible to protect both as best we can. Our knife holder is extra deep so that the blades remain steady throughout the wash cycle. There are knife holders on three levels: in the middle basket, in the upper basket and in the top basket. We guarantee a clean cut.
• Multi Position Glass Rack: The Multi position glass rack is a very practical rack that can be mounted in three different positions - all depending on your needs.
• Focus Points - A Hint of Nature: Opening the door of our new dishwasher can open your eyes to a few things. The high-grade steel might catch your attention at first. Then it may be one of the machine’s many clever features. These are highlighted with a color that mimics the ways in which nature brings focus to things. Closing the door puts the machine back in its place - where it doesn’t compete for space or attention - instead, it makes the room.
• 20 Years - Designed to Last: Today, sustainability and responsibility go hand in hand. So when we design our products, it is our responsibility to not only make products that last, but which also make things better - for our customers and for the planet. Designed to make a difference. And built to be enjoyed for the next 20 years.

Specifications

Appearance

• Type: Built-In
• Control Style: Fully-Integrated
• Color: Stainless Steel
• Accepts Panels: No
• Handle Design: Contemporary
• Handle Shape: Tubular
• Handle Type: Bar
• Handle Color: Stainless Steel

Details

• Tub Material: Stainless Steel
• Cycles: 7
• Number of Racks: 3
• Noise Level: 48 dBA
• Adjustable Racks: No
• Tall Tub: Yes
• Cutlery Tray: Yes

Features

• Capacity: 16 Place Settings
• Rinse Only Cycle: Yes
• Status Light: Yes
• Child Lock: Yes
• Delay Wash: Yes
• Water Softener: No
• Silverware Basket: Yes
• Leak Detection: Yes
• Sanitize Option: Yes
• AquaLevel Sensor: Yes
• Aqua Safe System: Yes
• 8Steel: Yes
• KidSafe: Yes
• Instant Lift: Yes
• Condensation Dry: Yes
• Brushless Motor: Yes
• Rinse and Hold: Yes
• Time Program: Yes
• Flexiracks: Yes
• XXL Dishwashers: Yes
• Self-Cleaning Program: Yes
• Speed Mode: Yes
• Night Mode: Yes
• Power Zone Cutlery: Yes
• TouchProof: Yes
• Knife Holders: Yes
• Aqua Detect Sensor: Yes
• Pop Out Door: Yes
• Telescopic Rails: Yes
• 3 Spray Arm: Yes
• 7 Spray: Yes

Electrical Specifications

• Volts: 120 Volts
• Amps: 15 Amps
• Frequency: 60 Hz.

Technical Details

• Approved for Outdoor use: Yes
• Warranty Terms: Limited 2 Year Parts and Labor

Dimensions & Weight

• Width: 24 1/2"
• Depth: 24 15/16"
• Height: 34 11/16"
• Cord Length: 71 7/16"
• Cutout Depth: 25"
• Cutout Height: min. 34 1/2"
• Cutout Width: 24 9/16"
• Shipping Weight: 179 lbs.
• Net Weight: 159 lbs.

Downloads & Manual

• Dimensions

• Instructions for use
• Product sheet
