Calcana Model PH-75-20’ Standard Output, Outdoor Patio Heater, Natural Gas | Propane , Patented Modulating Control 37,500 to 75,000 Btu, Ventable

Calcana Model PH-75-20’ Standard Output, Outdoor Patio Heater, Natural Gas | Propane, Patented Modulating Control 37,500 to 75,000 Btu, Ventable Natural gas | Propane 21.5′ Standard output Model PH–75–20′ Venting shown in image does not come with unit Additional information Additional information Weight 2240 oz Dimensions 258 × 15 ×... read more

SKU: 5260209

Vendor: Calcana

Availability: 39 Qty In Stock

Product Type: Outdoor Heaters

FREE SHIPPING

Regular price: $3,076.76
Regular price: ~~$3,487.00~~
Sale price: $3,076.76
Unit price: per

Fuel Type: Natural Gas Natural Gas Propane

Product variants

Quantity

SHOP WITH CONFIDENCE

APPLIANCE GUYS STANDS BEHIND EVERY TRANSACTION

100%

Satisfaction Guaranteed

Easy Shipping

Price Match

Frequently bought together

PH 304 SS Overhead Mounting Kit Horizontal (3) - 3 Hanging points (PH-50-15, PH-75-20)

$299.20

$3,076.76

+

Bundle

$299.20

=

$3,375.96

Shipping & Returns

When Will My Item Arrive?

Once shipped, items usually arrive within 3–5 business days. If your item or order is large, it may ship via one of our third-party freight carriers, which deliver from semi trucks with lift gates. Freight delivery is much more complicated than standard parcel shipping — you must schedule a drop-off time, be present for the delivery, and move items from the curb to your residence, among other differences. Sound stressful? If you prepare in advance with ourguide to freight delivery, it doesn’t have to be.

We strongly encourage reading the entire freight delivery guide, but here’s aquick snapshot of what you need to be ready for when you order a large package:

Your freight carrier will call you to schedule a delivery window of about 4–8 hours
You’re required to be physically present at the specified delivery location during the scheduled window
Freight shipments are carried in semi trucks, which have lift gates to assist with unloading
Freight deliveries are dropped off at the curb and no further — not up the driveway, not the porch, not the garage, and most definitely not the backyard — so it’s on you to transport packages to their intended locatio
For an easier time hauling items to your home or backyard, arrange for at least 2 helpers to be on standby during your delivery window
You must sign for the shipment to indicate that you’ve accepted the delivery

Again, we recommend reading our entire breakdown of freight delivery so you can become familiar with the process. Trust us when we say that getting caught off guard with the strict requirements of freight delivery can lead to a whole lot of headaches.

This item leaves our warehouse within 30-Day Returns

Returns: Return all new, unused, and unassembled items in their original packaging, and we’ll give you a full refund minus the cost of the original AND return shipping. Made to order and special order items are not applicable for returns.

Restocking Fee: A 20% restocking fee will be applied to returned items.

Calcana Model PH-75-20’ Standard Output, Outdoor Patio Heater, Natural Gas | Propane, Patented Modulating Control 37,500 to 75,000 Btu, Ventable

Natural gas | Propane
21.5′
Standard output
Model PH–75–20′

Venting shown in image does not come with unit

Additional information

Weight	2240 oz
Dimensions	258 × 15 × 9 in

Inputs (BTU/Hr)

Model	Min	Max	Length
PH-40	20,000	40,000	10′
PH-50	25,000	50,000	15′
PH-75	37,000	75,000	20′
PH-40 (High Output)	20,000	40,000	5'
PH-75 (High Output )	37,000	75,000	10'

Gas Inlet Pressure:

Gas Type	Minimum	Maximum
Natural Gas Patio Heater	4.5″ W.C.	14.0″ W.C.
Propane Patio Heater	11.5″ W.C.	14.0″ W.C.

Gas Pressure at Manifold:

Natural Gas Patio Heater: 3.5″ W.C.

Propane Patio Heater (LP Gas): 10.5″ W.C.

Gas Connection Size: 0.5″ N.P.T.

Patio Heaters’ Electrical Ratings:

DSI Ignition

120v, 60 Hz, 1 Amp/24 volt power supply

24 volt low voltage On/Off- Hi/Lo Variable Control Panel

Patio Heaters’ Standard Equipment

Burner control housing is preassembled and pre–wired, unit comes complete with industry standard gas, electrical, balanced air rotor, thermal overload protected motor, visual burner inspection sight glass, combustion and air proving safety switch, electronic 3–try spark ignition control, 100 percent safety shut–off, low voltage control connection, 4″ heat treated aluminized combustion tube, aluminum standard reflector (HO models: stainless steel patio heaters), tube couplers, heat economizer baffle, stainless steel hangers, decorative grille, indicator light, stainless steel burner head construction.

Benefits

More warmth with 40% less fuel — efficient
Heat–treated aluminized steel infrared emitters — long-lasting outdoor heaters
Sleek, sophisticated, graceful design — see our patio heaters gallery…>
No open flames or glowing red parts — safe outdoor heater
Low clearance to combustibles — can be installed in tight spaces where other outdoor heaters can’t
A modulating burner for a wide variety of incremental adjustments — ideal comfort
Stainless steel construction – durable, low maintenance outdoor heaters

Manuals & Warranty

Video

Need More Help?

Our expert can help guide you through
your purchase.

Call Now (833)268-8743
or send us an email

Calcana Model PH-75-20’ Standard Output, Outdoor Patio Heater, Natural Gas | Propane, Patented Modulating Control 37,500 to 75,000 Btu, Ventable

Natural gas | Propane
21.5′
Standard output
Model PH–75–20′

Venting shown in image does not come with unit

Need More Help?

Our expert can help guide you through
your purchase.

Call Now (833)268-8743
or send us an email

Related Departments

About the Manufacturer

Manufacturer's Name Calcana

Our heaters are known as the Best Heaters on the market today. Our sophisticated designed heaters are made from Stainless Steel 304 or Marine Grade 316 material to withstand the most harsh weather that mother nature can surprise us with this time of year
