SunGold Power - 6.5KW 48V Split Phase Solar Inverter SPH6548P
The 6.5KW Pure Sine Wave Solar Inverter features a max 140A battery charging with 2 MPPT solar controllers, max open circuit voltage of 550VDC, and outputs as split phase (120V/240V) or single phase (120V). The included Wi-Fi module allows users to view operational status via a mobile app. It supports parallel... read more
SKU:
SPH6548P
Vendor:
SunGold Power
Availability:
Available to order
Product Type:
Power inverter
FREE SHIPPING
- Regular price
- $1,350.00
- Regular price
-
- Sale price
- $1,350.00
- Unit price
- per
SHOP WITH CONFIDENCE
APPLIANCE GUYS STANDS BEHIND EVERY TRANSACTION
100%
Satisfaction Guaranteed
Easy Shipping
Price Match
When Will My Item Arrive?
Once shipped, items usually arrive within 3–5 business days. If your item or order is large, it may ship via one of our third-party freight carriers, which deliver from semi trucks with lift gates. Freight delivery is much more complicated than standard parcel shipping — you must schedule a drop-off time, be present for the delivery, and move items from the curb to your residence, among other differences. Sound stressful? If you prepare in advance with ourguide to freight delivery, it doesn’t have to be.
We strongly encourage reading the entire freight delivery guide, but here’s aquick snapshot of what you need to be ready for when you order a large package:- Your freight carrier will call you to schedule a delivery window of about 4–8 hours
- You’re required to be physically present at the specified delivery location during the scheduled window
- Freight shipments are carried in semi trucks, which have lift gates to assist with unloading
- Freight deliveries are dropped off at the curb and no further — not up the driveway, not the porch, not the garage, and most definitely not the backyard — so it’s on you to transport packages to their intended locatio
- For an easier time hauling items to your home or backyard, arrange for at least 2 helpers to be on standby during your delivery window
- You must sign for the shipment to indicate that you’ve accepted the delivery
Again, we recommend reading our entire breakdown of freight delivery so you can become familiar with the process. Trust us when we say that getting caught off guard with the strict requirements of freight delivery can lead to a whole lot of headaches.
This item leaves our warehouse within 30-Day Returns
Returns: Return all new, unused, and unassembled items in their original packaging, and we’ll give you a full refund minus the cost of the original AND return shipping. Made to order and special order items are not applicable for returns.
Restocking Fee: A 20% restocking fee will be applied to returned items.
The 6.5KW Pure Sine Wave Solar Inverter features a max 140A battery charging with 2 MPPT solar controllers, max open circuit voltage of 550VDC, and outputs as split phase (120V/240V) or single phase (120V). The included Wi-Fi module allows users to view operational status via a mobile app. It supports parallel operation of up to 6 units for a total of 39KW output, ensuring stable AC output with smart protection like PV input over-voltage and battery over-voltage protection. It offers four charging/output modes and a time-slot charging/discharging function to optimize utility power and PV energy use. Compatible with 48V AGM/Sealed, Gel, Flooded, Lithium batteries, and supports CAN and RS485 communication.
Features
- All in One Unit: 6.5KW Pure Sine Wave Solar Inverter with 140A battery charging, 2 MPPT solar controllers, 550VDC max. open circuit voltage, split phase (120V/240V) or single phase (120V) output, includes Wi-Fi module for mobile app monitoring.
- Parallel Kit: Supports parallel operation of up to 6 units for a total of 39KW power output, providing 120V single phase, 120V/240V split phase, or 208V 3-phase (more than 3 units in parallel).
- Stable AC Output and Smart Protection: Rated output power of 6500W, max peak power of 13,000VA, with protection against PV input over-voltage/current, AC input over-voltage, battery over-voltage, and overload.
- Charging/Output Modes: Hybrid Charging, Utility Priority Charging, Solar Priority Charging, Only Solar Charging; 4 output modes: Utility Priority, Solar and Utility Hybrid, Solar Priority, Inverter Priority.
- Time-slot Charging/Discharging Function: Allows setting of different charging/discharging periods based on local tariffs for optimal utility power and PV energy usage.
- Battery Type: Supports 48V AGM/Sealed, Gel, Flooded, Lithium batteries and User Mode, including battery-free operation and activation of dormant lithium batteries via mains power and photovoltaics; supports CAN and RS485 communication with SunGoldPower batteries.
Specifications
Inverter Output:
- Rated Output Power: 6500W
- Max. Peak Power: 13,000 VA
- Rated Output Voltage: 120/240Vac (split phase/single phase)
- Rated AC Frequency: 50/60Hz
- Output wave: Pure Sine Wave
- Switch Time: 10ms (typical)
- Parallel number: 6
Battery:
- Battery Type: Lithium-ion battery/lead-acid battery/user-defined battery
- Rated Battery Voltage: 48Vdc
- Voltage Range: 40Vdc-60Vdc
- Max. Mains/Generator Charging Current: 80A
- Maximum mix charge current: 140A
PV Input:
- MPPT channel number: 2
- Maximum input power: 5000W+5000W
- Maximum Input Current: 18/18A
- Maximum open circuit voltage: 550Vdc+550Vdc
- MPPT operating voltage range: 150Vdc-450Vdc
Mains/generator Input:
- Input Voltage Range: 65 VAC-140 VAC
- Input frequency range: 50/60Hz
- Bypass Overload Current: 40A
Efficiency:
- MPPT Tracking Efficiency: 99.9%
- Maximum efficiency of battery inverter: 93%
General:
- Dimensions: 23.0 inch x 16.1 inch x 5.23 inch (584.6mm x 410 mm x 133 mm)
- Weight: 41.7lb (18.9 kg)
- Protection level: IP20, for indoor use only
- Operating Temperature Range: 14-131°F, >113°F derating (-10~55°C >45°C derating)
- Noise: <60dB
- Cooling Method: Internal Fan
Communication:
- Embedded Interfaces: RS485 / CAN / USB / Dry contact
- External Modules (Optional): Wi-Fi / GPRS
